GE Multilin F650 Digital Bay Controller 4-31
4 HUMAN INTERFACES 4.1 ENERVISTA 650 SETUP SOFTWARE INTERFACE
4
4.1.9 OPERATIONS MENU OVERVIEW
Option only available in on line mode, showing all the operations previously configured in the relay with their corresponding
texts.
Table 4–24: GENERAL OVERVIEW OF OPERATIONS MENU:
Options enabled only in On-line mode are marked as (*). Options enabled only in Off-line mode are marked as (**)
4.1.10 COMMUNICATION MENU OVERVIEW
The communication menu includes the computer screen to start communicating with the relay, the different update
procedures available in device: firmware, boot code, web server and other file storing capabilities (upload and download
info files to/from relay).
For more detail information go to section starting communication for communication menus description and to section for
flash memory update procedures.
Table 4–25: GENERAL OVERVIEW OF COMMUNICATION MENU:
Options enabled only in On-line mode are marked as (*). Options enabled only in Off-line mode are marked as (**)
OPERATIONS
Operation 1 (*) Entry to first operation (with its corresponding text)
... ...
Operation 24 (*)
Entry to 24
th
operation (with its corresponding text)
COMMUNICATION
Computer Menu to start communication with the relay.
Modem (**) Menu to set modem communication parameters (only available if control
type is set to modem in computer menu).
Troubleshooting (*) Menu that Lets the user to perform reading or writing in ModBus
addresses, for verifying communications and access to different
positions in the ModBus memory map.
Calibration (*) Retrieval and store calibration settings from/to relay.
Upgrade firmware
version (**)
Menu to update the relay firmware version through Ethernet
Upgrade boot code (**) Menu to update the relay boot code (front RS323 and Ethernet
connection)
Upgrade F650 web
server
Menu to update the web server application (if available)
Upload info files to
relay
Hard disk storage of settings and configuration files on the relay.
Download info files
from relay
Retrieval of settings and configuration files that had been previously
stored in the relay hard disk.
