4 HUMAN INTERFACES 4.2 HUMAN MACHINE INTERFACE (HMI)
4
Figure 4–19: shows an example of snapshot events navigation:
Press shuttle key from the default main screen and enter in the main text menu.
Move the shuttle key until a single scroll bar character appears in the left part of
Snapshot event header.
Press shuttle key to enter in the snapshot events menu
Select the snapshot event to display using the shuttle key (left and right to move up
and down inside the recorded snapshot events).
Once selected the snapshot event, identifier , status, date and time will be displayed.
In the second line St: is showing the status and the relative snapshot index from the
whole recorded number. Third and fourth lines are used to display the time and date
of the snapshot event.
Pressing the shuttle key the metering screen for the snapshot event will be
displayed.
To exit from this screen press the ESC key and return to the snapshot events menu.
Figure 4–19: SNAPSHOT EVENTS NAVIGATION IN HMI
A ctu al V alu es
? S nap sh o t even t
Fault report
V iew setting s
ENTER
ESC
L–R
ENTER
ESC
Isolated G nd3 B lock>
S t: O F F (5 /4 7 9 )
T im e: 16:35:01.995
D a te : 1 0 /J u n /2 0 0 5
B reaker C losed O N >
S t: O N (4 /4 7 9 )
T im e: 16:35:02.027
D a te : 1 0 /J u n /2 0 0 5
F 650 2.00 (3.0)
G en eral E lectric
F 650M Z D F2G 1H IR
19200N 81: M O DBUS: 254
ENTER
ESC
Ia 0.000
V
ab 0.000
Ib 0.000 V b c 0.000
Ic 0.000 V ca 0.000
Ig 0.000 V 0 0.000
