GE Multilin F650 User Manual

4-56 F650 Digital Bay Controller GE Multilin
4.2 HUMAN MACHINE INTERFACE (HMI) 4 HUMAN INTERFACES
4
4.2.6.2 METERING SCREEN
The Metering screen displays relay analog measures in their primary values. Available metering values are as follows:
Figure 4–28: METERING SCREEN
As in the rest of graphical display screens, the bottom part shows a legend that indicates the possible options for the user.
In this case, the options are:
Intro: Next.Esc: Prev.L-R: Scroll.
Intro: Next.
Pressing the shuttle key the user accesses the next screen, in this case the ALL EVENTS screen.
Esc: Prev.
Pressing the ESC key the user returns to the previous screen (One-line diagram)
L-R: Scroll.
Rotating the shuttle key to the left (L) or right (R) the user can access all the Metering values in the screen. Rotating the
shuttle key left will move up in the screen, and rotating right will move down.
METERING SCREEN ANALOG MEASURES IN PRIMARY VALUES
Phasor Ia Primary V0 Primary Phase A Real Pwr Line Frequency Primary
Phasor Ib Primary V1 Primary Phase B Reactive Pwr Bus Frequency Primary
Phasor Ic Primary V2 Primary Phase B Apparent Pwr Vx Primary
Phasor Ig Primary Vab Primary Phase B Real Pwr Positive MVarhour
Phasor Isg Primary Vbc Primary Phase C Reactive Pwr Negative MVarhour
Phasor In Primary Vca Primary Phase C Apparent Pwr Positive MWatthour
RMS Ia Primary Vn Primary Phase C Real Pwr Negative MWatthour
RMS Ib Primary Va Primary 3 Phase Reactive Pwr Pos MVarhour Cnt
RMS Ic Primary Vb Primary 3 Phase Apparent Pwr Neg MVarhour Cnt
RMS Ig Primary Vc Primary 3 Phase Real Pwr Pos MWatthour Cnt
RMS Isg Primary VBB Primary Phase A Power Factor Neg MWatthour Cnt
I0 Primary VL Primary Phase B Power Factor
I1 Primary Phase A Reactive Pwr Phase C Power Factor
I2 Primary Phase A Apparent Pwr 3 Phase Power Factor
Metering Screen. Total meterin
g
5
6
Phasor Ia Primary 0.000 KA
Phasor Ib Primary 0.000 KA
Phasor Ic Primary 0.000 KA
Phasor Ig Primary 0.000 KA
Phasor Isg Primary 0.000 KA
RMS Ia Primary 0.000 KA
RMS Ib Primary 0.000 KA
RMS Ic Primary 0.000 KA
RMS Ig Primary 0.000 KA
RMS Isg Primary 0.000 KA
I0 Primary 0.000 KA
Intro: Next. ESC: Prev L-R:Scroll.
