GE Multilin F650 Digital Bay Controller 5-89
5 SETPOINTS 5.5 CONTROL ELEMENTS
5
5.5.5.4 AUTORECLOSE INTERNAL STATUS
Actual> Status > Control Elements > Autoreclose. These signals can be used as conditions for executing logics in the
relay; they are also useful to know the autoreclose behavior.
Table 5–77: 79 INTERNAL STATUS
Description of autoreclose internal status:
AR CLOSE BREAKER Breaker close command given by the autoreclose
AR OUT OF SERVICE Autoreclose out of service (Disabled)
AR READY Autoreclose in service
AR LOCKOUT Autoreclose in lockout status (finished cycled-definite trip)
AR BLOCK Autoreclose blocked (by input, logic, others, etc).
AR RCL IN PROGRESS Cycle in course (autoreclose in progress).
AR LCK BY ANOMALY Autoreclose in “Lockout” by anomaly.
AR LCK BY FAIL OPEN Autoreclose in “Lockout” by failure to open
AR LCK BY FAIL CLOSEAutoreclose in “Lockout” by failure to close
AR LCK BY USER Autoreclose in “Lockout” by user Command; manual breaker close during the autoreclose cycle
AR LCK BY CONDS Autoreclose in lockout by non-compliance of the autoreclose conditions
AR LCK BY TRIPS Autoreclose in “Lockout” by maximum number of trips (Lockout status not available)
AR LCK BY SHOTS Autoreclose in “Lockout” at the end of cycle – Definite trip (due to Maximum Number of shots
reached).
AR BLK AFTER 1 SHOT Block signal sent by the autoreclose after the first shot
AR BLK AFTER 2 SHOT Block signal sent by the autoreclose after the second shot
AR BLK AFTER 3 SHOT Block signal sent by the autoreclose after the third shot
AR BLK AFTER 4 SHOT Block signal sent by the autoreclose after the fourth shot
AR BLOCK BY LEVEL Autoreclose blocked by level. See AR block signals configuration (AR LEVEL BLOCK)
AUTORECLOSE SINGLE STATUS AUTORECLOSE ENUMERATED STATUS
AR CLOSE BREAKER
AR STATUS
AR OUT OF SERVICE AR READY
AR READY AR LOCKOUT
AR LOCKOUT AR BLOCK
AR BLOCK AR RCL IN PROGRESS
AR RCL IN PROGRESS
AR LOCKOUT MODE
AR LCK BY ANOMALY AR LCK BY ANOMALY
AR LCK BY FAIL OPEN AR LCK BY FAIL OPEN
AR LCK BY FAIL CLOSE AR LCK BY FAIL CLOSE
AR LCK BY USER AR LCK BY USER
AR LCK BY CONDS AR LCK BY CONDS
AR LCK BY TRIPS AR LCK BY TRIPS
AR LCK BY SHOTS AR LCK BY SHOTS
AR BLK AFTER 1 SHOT
AR BLOCK MODE
AR BLK AFTER 2 SHOT AR BLOCK BY LEVEL
AR BLK AFTER 3 SHOT AR BLOCK BY PULSE
AR BLK AFTER 4 SHOT
AR BLOCK BY LEVEL
AR BLOCK BY PULSE
