GE Multilin F650 Digital Bay Controller G-1
APPENDIX G G.1 MISCELLANEOUS
G
APPENDIX G APPENDIX G. G.1MISCELLANEOUS G.1.1 F650 FIRMWARE REVISION HISTORY
FIRMWARE
VERSION
BOOT
PROGRAM
VERSION
CHANGES DESCRIPTION MODELS DATE
1.00 2.00 First version of the product (Basic Model F1G0)
Full protection scheme
F650BABF1G0HI
June 28
th
2002
1.11 2.00 New model F2G0 (inputs and outputs board type 2) F650BABF2G0HI
October 14
th
2002
1.13 2.20 Snapshot Events included (New and All)
Oscillography up to 4 records. Maximum 70 cycles at 64 samples
per cycle, trip programmable via PLC.
Broken Conductor protection function included.
Boot program updated through F650PC program
ALL December
20
th
2002
1.14 2.20 DNP 3.0 Level 2 protocol included, over TCP/IP and UDP/IP
IRIG_B synchronization
ALL
January 22
nd
2003
1.20 2.25 Programmable Graphical display
Calibration included to improve measurement accuracy
ALL
January 28
th
2003
1.30 2.25 Sensitive ground directional unit
Isolated Ground directional unit (in 5
th
current transformer)
Energy measurements
ALL
March 31
st
2003
1.31 2.25 Enhancements in 60 Hz measurements
Extended Settings Range in Negative Sequence Overcurrent
function (46)
ALL
April 9
th
2003
1.33 2.30 Forward Power function (32FP)
Demand
ALL
May 9
th
2003
1.44 2.30 51PL function included (besides existing 51PH)
Control Events
Alarms
ModBus over TCP/IP
ALL
July 24
th
2003
1.48 2.30 Changes in 67 units in reverse mode
ModBus TCP/IP enhancement
ALL September
5
th
2003
1.50 2.30 PROTECTION
The following operation curves have been added to F650
functionality:
IEC Long-Time Inverse
IEC Short-Time Inverse
ANSI Extremely Inverse
ANSI Very Inverse
ANSI Normally Inverse
ANSI Moderately Inverse
Rectifier Curve
User Curve A/B/C/D - Flex Curveî„
Note: User Curves allow the user to program any non-standard
curve type by selecting, point by point, the Operation time.
HARDWARE
Voltage Range:Voltage Metering Range expanded from (2 to 200
Volts) to (2 to 275V)
CIO Module: For those applications requiring a high number of
inputs and outputs, F650 units can be connected to a CIO module
(Remote CAN Bus I/O module) for using up to 2 additional boards.
COMMUNICATIONS
ModBus Protocol:
ModBus User Map
Virtual Inputs (control over internal logic variables, which can be
used in the configurable logic).
DNP 3.0 Protocol
New Metering scale factors
Switchgear bits mapped to binary points
Possibility of restricting the binary points map by setting
USER INTERFACE
HMI Configurable Main Screen:
The main screen offers the possibility to select the initial logo, a
simplified Metering screen showing primary values, or both.
Snapshot Events:
Possibility of viewing snapshot events from the relay display in
models without graphical display.
ALL
October 31
st
2003
