GE Multilin F650 User Manual

4-36 F650 Digital Bay Controller GE Multilin
4.2 HUMAN MACHINE INTERFACE (HMI) 4 HUMAN INTERFACES
4
4.2.5 TEXT MENUS
4.2.5.1 NAVIGATION IN TEXT MENU
Text menu is available for all models, this is the main menu for visualizing actual values, metering, changing settings, etc.
through the HMI. In models with graphical display (M in ordering code) besides this text main menu there are several
screens providing more performance for control purposes.
Press (or rotate left or right) the shuttle key to enter the main menu, starting from the standby screen (default main screen).
The default main screen can be accessed pressing ESC key till it appears. In all the navigation Press the shuttle key to
select the desired header display (top-level menu). Each press of the shuttle key advances through the main heading
pages as illustrated below. To return to previous menus press the ESC key. To move inside the top-level menu without
changing to other low levels, rotate the shuttle key left to move up and right to move down.
When rotating the shuttle key the selected menu is marked by a single scroll bar character. The mark (>) in the right part of
any menu means that contains more than one level.
Figure 4–17:shows an example of main menu navigation:
Figure 4–17: NAVIGATION IN MAIN TEXT MENU
Symb
o
l Action performe
d
Navigation in menu
ENTER Press Shuttle Key Enter next level
ESC Press Esc Key Exit to previous level
L–R Rotate Shuttl e Key move up and down in the
same le
vel
L Rotate Left Shuttle Key move up in the same level
R Rotate Right Shuttle Key move down in the same level
?
Menu selection Menu selection
> More menus to display More menus to display
F650 2.00 (3.0)
General El ectr ic
F650MZDF2G1HIR
19200N81: MODBUS: 254
Actual Values
Snapshot event
Fault report
View settings
Change Settings
Date & Time
Commands
Passwords
Select Main Scr een
Sel ect Language
 return
* Front Panel
>
Status >
Metering >
Inputs/Outputs
>
* Logotype
>
Metering >
All >
 return
ENTER
ESC
* Product Setup
>
Syst em Setup >
Protection Element >
Control Elements >
L–R
ENTER
ESC
