GE Multilin F650 User Manual

6-16 F650 Digital Bay Controller GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
6.2.8 SWITCHGEAR STATUS
Actual > Status > Switchgear Status
For a better understanding of the represented statuses in this screen, figure 6.1 shows the available “Switchgear” modules
to be programmed in the F650. Each of them has a series of inputs/outputs that are the statuses represented on this
screen. Separate signal for each switchgear device (for 1 to 16).g
Each Switchgear module can be programmed at: Setpoint > Relay Configuration >Switchgear, and its statuses are as
follows:
Table 6–24: SWITHGEAR STATUS
SWITCH X A INPUT The LED will light up when the input associated to that switchgear Contact A is activated.
SWITCH X B INPUT The LED will light up when the input associated to that switchgear Contact B is activated.
SWITCH X A STATUS Status associated to Switchgear contact A. It is activated once the time required for the
Switchgear module to acknowledge contact A has expired.
SWITCH X B STATUS Status associated to Switchgear contact B. It is activated once the time required for the
Switchgear module to acknowledge contact B has expired..
SWITCH X OPEN Lights up when the associated switchgear is open
SWITCH X CLOSED Lights up when the associated switchgear is closed
SWITCH X 00_ERROR Output that represents the Switchgear status 00, considered as abnormal.
SWITCH X 11_ERROR Output that represents the Switchgear status 11, considered as abnormal.
SWITCH X OPEN INIT Programmable input that indicates the initiation of the Opening Operation for the considered
switchgear.
SWITCH X CLOSE INIT Programmable input that indicates the initiation of the closing Operation for the considered
switchgear.
SWGR X FAIL TO OPEN Output that represents a failure to open, from the associated external device (opening time
exceeded)
SWGR X FAIL TO CLOSE Output that represents a failure to close from the associated external device (closing time
exceeded)
SWITCHGEAR 1 STATUS SWITCHGEAR X STATUS SWITCHGEAR 16 STATUS
SWITCH 1 A INPUT … SWITCH X A INPUT … SWITCH 16 A INPUT
SWITCH 1 B INPUT … SWITCH X B INPUT … SWITCH 16 B INPUT
SWITCH 1 A STATUS … SWITCH X A STATUS … SWITCH 16 A STATUS
SWITCH 1 B STATUS … SWITCH X B STATUS … SWITCH 16 B STATUS
SWITCH 1 OPEN … SWITCH X OPEN … SWITCH 16 OPEN
SWITCH 1 CLOSED … SWITCH X CLOSED … SWITCH 16 CLOSED
SWITCH 1 00_ERROR … SWITCH X 00_ERROR … SWITCH 16 00_ERROR
SWITCH 1 11_ERROR … SWITCH X 11_ERROR … SWITCH 16 11_ERROR
SWITCH 1 OPEN INIT … SWITCH X OPEN INIT … SWITCH 16 OPEN INIT
SWITCH 1 CLOSE INIT … SWITCH X CLOSE INIT … SWITCH 16 CLOSE INIT
SWGR 1 FAIL TO OPEN … SWGR X FAIL TO OPEN … SWGR 16 FAIL TO OPEN
SWGR 1 FAIL TO CLOSE … SWGR X FAIL TO CLOSE … SWGR 16 FAIL TO CLOSE
