3-12 F650 Digital Bay Controller GE Multilin
3.4 OPTIC FEATURES 3 HARDWARE
3
3.4OPTIC FEATURES
Wave length: 1300nm
Connector types: ST package style
Fiber type: multimode 62.5/125 m or 50/125 m
Notes:
1. These optical power values are measured with the following conditions:
The Beginning of Live (BOL) to the End of Life (EOL) optical power degradation is typically 1.5 dB per industry
convention for long wavelength LEDs. The actual degration observed in Agilent’s 1300nm LED products is <1 dB, as
specified in this data sheet.
Over the specified operating voltage and temperature ranges.
With HALT Line State, (12.5 MHz square-wave), input signal.
At the end of one meter of noted optical fiber with cladding modes removed.
The average power value can be converted to a peak power value by adding 3 dB. Higher output optical power
transmitters are available on special request.
Transmitter characteristics
Parameter
Min
.
Typ
.
Ma
x.
Unit Referenc
e
Output Optical Power BOL
62.5/125 m, NA = 0.275 Fiber
EOL
-19
-20
-14 dBm
avg.
Note 1
Output Optical Power BOL
50/125 m, NA = 0.275 Fiber
EOL
-
22.
5
-
23.
5
-14 dBm
avg.
Note 1
Output Optical Power at
Logic “0” State
-45 dBm
avg.
Note 2
Receiver characteristics
Parameter
Min
.
Typ
.
Ma
x.
Unit Referenc
e
Input Optical Power
Minimum at Window Edge
-
33.
9
-31 dBm
avg.
Note 3
Input Optical Power
Minimum at Eye Center
-
35.
2
-
31.
8
dBm
avg.
Note 4
Input Optical Power Maximum -14 dBm
avg.
Note 3
