GE Multilin F650 Digital Bay Controller 4-1
4 HUMAN INTERFACES 4.1 ENERVISTA 650 SETUP SOFTWARE INTERFACE
4
4 HUMAN INTERFACES 4.1ENERVISTA 650 SETUP SOFTWARE INTERFACE 4.1.1 OVERVIEW
This software package uses ModBus protocol, and it is designed to communicate with a single relay at a time. GE offers
different communication software packages, such as GE-POWER, which can be used to communicate simultaneously with
several relays.
EnerVista 650 Setup software provides an easy way to configure, monitor and manage all F650 features.
a )Setting files
EnerVista 650 Setup software provides two ways of working with setting files:
1.OFF LINE Mode: Creating or editing setting files not connected to the relay, to be stored later in the proper unit.
2. ON LINE Mode: Connecting to the relay. This on line mode allows settings modifications, reading metering
values, internal status, oscillography records, event records, etc.
b) Configuration
The relay allows to fully program all the inputs, outputs, LEDs, control events, operations, block signals in
protection elements, switchgear, one line diagram in HMI, and create internal logic.
For simple relay configurations a direct configuration can be used (Relay configuration screen), and for more
complex configurations a PLC Editor tool is provided (Logic Configuration screen).
c) Monitoring of all metering values, internal states, inputs and outputs provided by F650 device.
d) Performing the previously configured operations
e) Updating of operating system, firmware version and web server utility.
f) One line diagrams configuration (bay mimics) for its use in models with graphical display only.
g) Registering data info for control events, snapshot events, alarms, fault reports, oscillography files, data logger, etc.
