GE Multilin F650 User Manual

B-24 F650 Digital Bay Controller GE Multilin
B.1 MODBUS PROTOCOL FOR 650 APPENDIX B
B
B.1.7 MEMORY MAP
The Memory map can be obtained from EnerVista 650 Setup software, menu:
View > ModBus Memory map
ADDRESS Bit Name Format Step Mode Length Miscellaneous
0x0087 0x2000 CONT IP_F_CC2 F001 R 1
... ... ... ... .... ... ... ...
0x0089 0x0800 CONT IP_F_CC32 F001 R 1
Estado Señales Activación salidas Tarjeta F (16 elementos) - Board F: Contact Output Operate -logical status-
0x0089 0x1000 CONT OP OPER_F_01 F001 R 1
0x0089 0x2000 CONT OP OPER_F_02 F001 R 1
... ... ... ... ... ... ... ...
0x008A 0x0800 CONT OP OPER_F_16 F001 R 1
Estado Señales Reposición de Salidas Tarjeta F (16 elementos) - Board F: Contact Output Resets
0x008A 0x1000 CONT OP RESET_F_1 F001 R 1
0x008A 0x2000 CONT OP RESET_F_12 F001 R 1
... ... ... ... ... ... ... ...
0x008B 0x0800 CONT OP RESET_F_16 F001 R 1
Estado Salidas Tarjeta F (16 elementos) - Board F: Contact Outputs -physical status-
0x008B 0x1000 CONT OP_F_01 F001 R 1
0x008B 0x2000 CONT OP_F_02 F001 R 1
... ... ... ... ... ... ... ...
0x008C 0x0800 CONT OP_F_16 F001 R 1
Estado Tarjeta F - Board F Status
0x008C 0x1000 BOARD F STATUS F001 R 1
Estado Entradas Tarjeta G (32 elementos) - Board G: Contact Input Status
0x00AC 0x2000 CONT IP_G_CC1 F001 R 1
0x00AC 0x4000 CONT IP_G_CC2 F001 R 1
... ... ... ... ... ... ... ...
0x00AE 0x1000 CONT IP_G_CC32 F001 R 1
Estado Señales Activación salidas Tarjeta G (16 elementos) - Board G: Contact Output Operate -logical status-
0x00AE 0x2000 CONT OP OPER_G_01 F001 R 1
0x00AE 0x4000 CONT OP OPER_G_02 F001 R 1
... ... ... ... ... ... ... ...
0x00AF 0x1000 CONT OP OPER_G_16 F001 R 1
Estado Señales Reposición de Salidas Tarjeta G (16 elementos) - Board G: Contact Output Resets
0x00AF 0x2000 CONT OP RESET_G_01 F001 R 1
0x00AF 0x4000 CONT OP RESET_G_02 F001 R 1
... ... ... ... ... ... ... ...
0x00B0 0x1000 CONT OP RESET_G_16 F001 R 1
Estado Salidas Tarjeta G (16 elementos) - Board G: Contact Outputs -physical status-
0x00B0 0x2000 CONT OP_G_01 F001 R 1
0x00B0 0x4000 CONT OP_G_02 F001 R 1
... ... ... ... ... ... ... ...
0x00B1 0x1000 CONT OP_G_16 F001 R 1
