5-6 F650 Digital Bay Controller GE Multilin
5.2 PRODUCT SETUP 5 SETPOINTS
5
‱ Fault current and voltages in primary values
‱Fault type
‱ Distance to the fault (fault location)
‱ Line parameters
‱ Recloser and breaker status information
As an option, the Relay offers the possibility to display a fault-warning message on the relay HMI (selectable by setpoint).
5.2.3.2 FAULT REPORT SETPOINTS
Table 5–8: FAULT REPORT SETPOINTS
Function permission (Function): Enabling this setpoint allows to create a fault report when the FAULT REPORT TRIGG
is activated.
Positive sequence impedance module (Pos Seq Module): Value in ohms of the line positive sequence impedance
module.
Positive sequence impedance Angle (Pos Seq Angle): Value in degrees of the line positive sequence angle.
Zero sequence impedance module (Zero Seq Module): Value in ohms of the line zero sequence impedance module.
Zero sequence impedance Angle (Zero Seq Angle): Value in degrees of the line zero sequence angle.
Line Length: The metering unit can be kilometers or miles.
Show Fault On HMI: This setpoint enables or disables the option to display faults on the Relay HMI.
Snapshot Events: This setpoint enables or disables the snapshot event generation for the fault report unit.
5.2.3.3 FAULT REPORT STATES
States associated to the fault report (“Actual >Metering>Records Status>Fault Reports”), are shown on Table 5–9:
Table 5–9: FAULT REPORT STATES
SETPOINT > PRODUCT SETUP > FAULT REPORT
setpoint Description Name Default Value Step Range
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Positive sequence impedance module Pos Seq Module 3.00 0.01 Ohm [0.01 : 250.00]
Positive sequence impedance angle Pos Seq Angle 75 1 Deg [25 : 90]
Zero sequence impedance module Zero Seq Module 9.00 0.01 Ohm [0.01 : 750.00]
Zero sequence impedance angle Zero Seq Angle 75 1 Deg [25 : 90]
Line length Line Length 100.0 0.1 [0.0 : 2000.0]
Display fault on HMI Show Fault On HMI DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
FAULT REPORT STATES
FAULT REPORT TRIGG
CLEAR FAULT REPORTS
FAULT DATE
FAULT TYPE
FAULT LOCATION
FAULT REPORT NUMBER
