2-4 F650 Digital Bay Controller GE Multilin
2.3 ORDERING CODE 2 PRODUCT DESCRIPTION
2
2.3ORDERING CODE
F650 units are supplied as ½ 19” rack, 6 units high devices, containing the following modules: power supply, CPU, I/O
modules, communication modules. Each of these modules can be supplied in different versions that must be specified
when ordering. The required information to completely define an F650 model is shown on TABLE 2-1.
Table 2–2: ORDERING CODE
SPECIAL MODELS: MOD001: 6A output contacts instead of 16A.
(*) Note: Russian language available only for basic display models.
For those applications requiring a high number of inputs and outputs, F650 units can be connected to a CIO module
(Remote CAN Bus I/O module) for using up to 2 additional boards.
F650 - - - F - G - - DESCRIPTION
B Basic display (4x20 characters)
M Graphic display (240x128 pixels)
REAR SERIAL COMMUNICATIONS BOARD 1
F None
A Redundant RS485
P Redundant plastic fiber optic
G Redundant glass fiber optic
X Redundant RS485 + fiber remote CAN bus I/O
Y Redundant plastic fiber optic + fiber remote CAN bus I/O
Z Redundant glass fiber optic + fiber remote CAN bus I/O
C Cable remote CAN Bus I/O
M RS485 + cable remote CAN Bus I/O
REAR ETHERNET COMMUNICATIONS BOARD 2
B 10/100 Base TX
C 10/100 Base TX + 100 Base FX
D 10/100 Base TX + Redundant 100 Base FX
E Redundant 10/100 Base TX
I/O BOARD IN SLOT F
1 16 Digital Inputs + 8 Outputs
2 8 Digital Inputs - 8 Outputs + 2 trip/close circuit supervision
circuits
I/O BOARD IN SLOT G
0 None
1 16 Inputs + 8 Outputs
AUXILIARY VOLTAGE
LO 24-48 Vdc (range 19.2 – 57.6)
HI 110-250 Vdc (range 88 – 300)
120-230 Vac (range 96 – 250)
LOR Redundant LO
HIR Redundant HI
LANGUAGE
English/English
F French/English
P Russian/English (*)
S Spanish/English
