GE Multilin F650 Digital Bay Controller C-7
APPENDIX C C.1 DNP 3.0 PROTOCOL FOR F650
C
C.1.3 IMPLEMENTATION TABLE
The following table shows objects, variations, function codes and qualifiers supported by F650 units, both in requests and
responses for DNP3 protocol. For static (non-change-event) objects, requests sent with qualifiers 00, 01, 06, 07 or 08, will
be responded with qualifiers 00 or 01. Static object requests sent with qualifiers 17 or 28 will be responded with qualifiers
17 or 28. For change-event objects, qualifiers 17 or 28 are always responded.
Text in bold and italic indicates functionality higher than DNP3 implementation level 2.
a) IMPLEMENTATION TABLE (SHEET 1 OUT OF 3)
Note 1: A default variation refers to the variation responded when variation 0 is requested and/or in class 0, 1, 2, or 3 scans.
Note 2: For static (non-change-event) objects, qualifiers 17 or 28 are only responded when a request is sent with qualifiers 17 or 28,
respectively. Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01
(for change-event objects, qualifiers 17 or 28 are always responded).
Note 3: Cold restarts are implemented the same as warm restarts – The F650 is not restarted, but the DNP process is restarted.
OBJECT REQUEST RESPONSE
Object
No.
Variation
No.
Description
Function Codes
(dec)
Qualifier Codes
(hex)
Function Codes
Qualifier Codes
(hex)
10
Binary Input (Variation 0 is used to
request default variation)
1 (read)
22 (assign class)
06 (no range, or all)
00,01 (start-stop)
07,08 (limited qty)
17,28 (index)
1 1 Binary Input
1 (read)
22 (assign class)
00,01 (start-stop)
06 (no range, or all)
07,08 (limited qty)
17,28 (index)
129 (response)
00, 01 (start-stop)
17,28 (index)
See Note 2
12
Binary Input with Status
(default – see Note 1)
1 (read)
22 (assign class)
00,01 (start-stop)
06 (no range, or all)
07,08 (limited qty)
17,28 (index)
129 (response)
00, 01 (start-stop)
17,28 (index)
See Note 2
20
Binary Input Change - All Variations
See Note 1
1 (read)
06 (no range, or all)
07,08 (limited qty)
2 1 Binary Input Change without Time 1 (read)
06 (no range, or all)
07,08 (limited qty)
129 (response)
130 (unsol. resp.)
17, 28 (index)
2 2 Binary Input Change with Time 1 (read)
06 (no range, or all)
07,08 (limited qty)
129 (response)
130 (unsol. resp.)
17, 28 (index)
10 0 Binary Output - All Variations 1 (read)
06 (no range, or all)
00,01 (start-stop)
07,08 (limited qty)
17,28 (index)
10 2
Binary Output Status
See Note 1
1 read
00,01 (start-stop)
06 (no range, or all)
07,08 (limited qty)
17,28 (index)
129
(response)
00, 01 (start-stop)
17,28 (index)
See Note 2
12 1 Control Relay Output Block
3 (select)
4 (operate)
5 (direct op)
6 (dir.op, noack)
00,01 (start-stop)
07,08 (limited qty)
17, 28 (index)
129 (response) echo of request
20 0 Binary Counter - All Variations
1 (select)
7 (freeze)
8 (freeze noack)
9 (freeze clear)
10 (frz.cl. noack)
06 (no range, or all)
