GE Multilin F650 Digital Bay Controller 4-37
4 HUMAN INTERFACES 4.2 HUMAN MACHINE INTERFACE (HMI)
4
4.2.5.2 TEXT MENU HIERARCHY
The structure of HMI text menu is similar to the EnerVista 650 Setup in the actual values and settings (view and change)
menus.
The main menu shows the following options:
Table 4–29: GENERAL OVERVIEW OF MAIN TEXT MENU:
NAME DESCRIPTION NAVIGATION IN MENU
Actual Values Actual values of all the signals available in device.
Status of protection and control elements,
measurements, inputs and outputs, etc.
Press shuttle key to enter next level. Press ESC to
return to default main screen.
Snapshot events Visualization of all snapshot events in text mode (two
screens for each snapshot event). In graphical displays
there can be seen in a dedicated screen.
Press shuttle key to visualize snapshot events in text
menu. Press ESC to return to default main screen.
Fault Report Fault reports information available in HMI (two screens
for each fault report)
Press shuttle key to enter next level. Move L-R to see
all the available fault reports in device. Press shuttle
key to enter particular information for fault report
selected.
View Settings Visualization of all protection and control settings
available in device.
Press shuttle key to enter next level. Move L-R to
select submenu. Press ESC to return to previous
level.
Change Settings Menu that allows changing all protection and control
settings available in device. Inputs and outputs settings,
relay configuration and logic configuration are not
available in HMI, only via EnerVista 650 Setup
software.
Press shuttle key to enter next level. Move L-R to
select submenu. Press esc to return to previous level.
Date & Time Date and time visualization and modification by user First mode is visualization. Press again shuttle key to
start modification in date and time. Press ESC to
return to previous level.
Commands Operations execution in local mode. Move L-R to pre select operation. Press shuttle key to
select and confirm. Press ESC to return to previous
level.
Password Password menu for settings and commands Move L-R to select submenu. Press shuttle key to
enter next level. Press ESC to return to previous
level.
Select Main Screen Selection of default main screen in text menu. Move L-R to select the default main screen type.
Press shuttle key to confirm.
Select Language Language selection. Between default language (see
ordering code) and English.
Move L-R to select the default language. Press
shuttle key to confirm selection. Switch the relay off
and on.
< - return Return to previous level Press shuttle key to return to previous level.
