4.2 HUMAN MACHINE INTERFACE (HMI) 4 HUMAN INTERFACES
4
4.2.5.6 CHANGE SETTINGS
To enter this menu press the shuttle key when the option “Change Settings” is selected in main menu. A secondary level
will be displayed with different sublevels as shown on Table 4–31:. Rotating the shuttle key, (left for moving up and right for
moving down) select the next level to be displayed press the shuttle key again to enter in next level and press ESC key to
return to previous level if desired. This navigation will be performed the same for all the menus in “Change Settings”. Once
the last sublevel is reached, move up and down to visualize the settings selected.
To change a particular setting, press the shuttle key on the setting to be modified. After selecting the setting, the value for
that setting will appear between brackets. Choose the new value moving up and down the shuttle key. After selecting the
appropriate value press again the shuttle key to fix that value. To save the new settings, go to the end of the menu rotating
the shuttle key right, and select the menu “Press intro to save settings”. When pressing the shuttle key inside this menu the
new settings will be saved.
Figure 4–21: shows an example of change settings navigation:
Select the menu Change settings and press the shuttle key to enter in the next
sublevel.
If there is more than one sublevel, select the next sublevel by rotating and pressing
the shuttle key till the last level is reached.
Press the shuttle key in the function to be modified
-> Group of settings
-> Setting to be modified
-> Value
-> Range and step
Pressing the shuttle key, value appears between brackets and can be modified
rotating the shuttle key. Pressing again the shuttle key, the new value will be
accepted.
Once all settings inside the group have been modified, go to the last screen rotating
the shuttle key and press Intro. At this moment of time, the new settings will be
active in the relay.
Figure 4–21: CHANGE SETTINGS PROCEDURE IN HMI
S nap shot event
Fault report
V ie w s e ttin g s
* C han ge setting s
* G eneral Settings
B reaker >
 r e tu r n
Product Setup >
* S ystem S etup >
Protection Elem ents >
C o n tr o l E le m e n ts >
G eneral Settings
P h ase C T R atio
6.0
[ 1.0:6000.0:0.1]
G eneral Settings
P h ase C T R atio
<6>.0
[ 1.0:6000.0:0.1]
P r e s s In tr o
to s a v e s e ttin g s
