C-18 F650 Digital Bay Controller GE Multilin
C.1 DNP 3.0 PROTOCOL FOR F650 APPENDIX C
C
a) ANALOG INPUT POINTS
POINT INDEX NAME/DESCRIPTION POINT INDEX NAME/DESCRIPTION
0 Phasor Ia Primary 27 Phase A Apparent Pwr
1 Phasor Ib Primary 28 Phase A Real Pwr
2 Phasor Ic Primary 29 Phase B Reactive Pwr
3 Phasor Ig Primary 30 Phase B Apparent Pwr
4 Phasor Isg Primary 31 Phase B Real Pwr
5 Phasor In Primary 32 Phase C Reactive Pwr
6 RMS Ia Primary 33 Phase C Apparent Pwr
7 RMS Ib Primary 34 Phase C Real Pwr
8 RMS Ic Primary 35 3 Phase Reactive Pwr
9 RMS Ig Primary 36 3 Phase Apparent Pwr
10 RMS Isg Primary 37 3 Phase Real Pwr
11 I0 Primary 38 Phase A Power Factor
12 I1 Primary 39 Phase B Power Factor
13 I2 Primary 40 Phase C Power Factor
14 V0 Primary 41 3 Phase Power Factor
15 V1 Primary 42 Line Frequency Primary
16 V2 Primary 43 Bus Frequency Primary
17 Vab Primary 44 Vx Primary
18 Vbc Primary 45 Positive MVarhour
19 Vca Primary 46 Negative MVarhour
20 Vn Primary 47 Positive MWatthour
21 Va Primary 48 Negative MWatthour
22 Vb Primary 49 Pos MVarhour Cnt
23 Vc Primary 50 Neg MVarhour Cnt
24 VL Primary 51 Pos MWatthour Cnt
25 VBB Primary 52 Neg MWatthour Cnt
26 Phase A Reactive Pwr
