D-4 F650 Digital Bay Controller GE Multilin
D.1 IEC 60870-5-104 PROTOCOL APPENDIX D
D
D.1.4 IEC 104 SETTINGS
The Communication settings for IEC 60870-5-104 protocol are the following:
Function: Enable or disable the protocol operation.
TCP Port: Listening TCP port in the relay. Default value is 2404.
Common Addr of ASDU: Address in the ASDU header. Default value is 255.
Cyclic Meter Period: Number of seconds for instantaneous meterings. 0 means no spontaneous
meterings.
Synchronization event: Not implemented.
The F650 relay has a custom Binary Inputs points list, called User Map; it is common for any protocol. In the
case of IEC 104 Protocol, those points are GROUP1 and GROUP2.
The IEC 104 User Map can be configured using the
EnerVista 650 Setup software in Settings>Relay
Configuration->Control Events.
The User Map contains 128 Binary Inputs. To each point of the User Map,
the user can assign any of the binary states of the F650 relay, also is possible to combine those states using
OR and NOT functions. These states are: contact inputs and outputs, virtual outputs, protection element
states, PLC states, etc. The User Map always has a size of 128 Binary Inputs. Points in the User Map that are
not configured will have a zero value in the answer.
It is possible to implement more complex logic than simple OR and NOT using the
PLC Editor tool in
EnerVista 650 Setup in the menu Settings>Logic Configuration. These complex signals (Virtual Outputs)
can be assigned to the binary points in the Control Events configuration for the IEC 104 user map.
PRODUCT SETUP>COMMUNICATION SETTINGS >IEC 870-5-104
NAME VALUE UNITS RANGE
Function DISABLED
TCP Port 2404 [0 : 65535]
Common Addr of ASDU 255 [0 : 65535]
Cyclic Meter Period 0 [0 : 3600]
Synchronization Event 0 [0 : 3600]
