GE Multilin F650 Digital Bay Controller 6-7
6 ACTUAL VALUES 6.2 STATUS
6
6.2.3.9 POWER
Forward Power and directional power elements
There are three identical forward power and three directional power detection elements, each of them with two power-
setting levels.
Represented statuses are basically Pickup and Trip (Operation) for each step in each function.
This functions may have several applications, for example, small generating plants connected to the power system, to limit
the supplied power and not to exceed its rated capacity.
If programmed conditions for any of the three elements are met, the corresponding LEDs will light up.
This screen shows the activation of all power elements available in the F650. It can be accessed from the menu: Actual>
Status > Protection >Power, and it includes the following signaling LEDs.
Table 6–12: POWER ACTUAL VALUES
FORWARD POWER ACTUAL VALUES DIRECTIONAL POWER ACTUAL VALUES
FWD PWR1 STG1 PKP DIR PWR1 STG1 PKP
FWD PWR1 STG1 OP DIR PWR1 STG1 OP
FWD PWR1 STG2 PKP DIR PWR1 STG2 PKP
FWD PWR1 STG2 OP DIR PWR1 STG2 OP
DIR PWR1 STG PKP
DIR PWR1 STG OP
FWD PWR2 STG1 PKP DIR PWR2 STG1 PKP
FWD PWR2 STG1 OP DIR PWR2 STG1 OP
FWD PWR2 STG2 PKP DIR PWR2 STG2 PKP
FWD PWR2 STG2 OP DIR PWR2 STG2 OP
DIR PWR2 STG PKP
DIR PWR2 STG OP
FWD PWR3 STG1 PKP DIR PWR3 STG1 PKP
FWD PWR3 STG1 OP DIR PWR3 STG1 OP
FWD PWR3 STG2 PKP DIR PWR3 STG2 PKP
FWD PWR3 STG2 OP DIR PWR3 STG2 OP
DIR PWR3 STG PKP
DIR PWR3 STG OP
