GE Multilin F650 User Manual

2-24 F650 Digital Bay Controller GE Multilin
2.4 TECHNICAL SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
2.4.11 ENVIRONMENTAL CHARACTERISTICS
2.4.12 PACKAGING AND WEIGHT
Protocols available:
ModBus
®
RTU / DNP 3.0
Typical distance: 1200 m
Isolation: 2 kV
CAN PORT:
Rear port: CAN port in models X, Y, Z for asynchronous rear ports
Type: Multimode glass F.O. port with ST connectors
Wave length: 1300 nm
Fiber type:
multimode 62.5/125 m or 50/125 m
Isolation: 2 kV
ETHERNET PORT:
Rear port: COM3
Type (depending on model):
Model B: 10/100BaseTX self-negotiable
Model C: 10/100BaseTX + 100Base FX
Model D: 10/100BaseTX + Double 100BaseFX (Physical media redundancy)
10/100BaseTX RJ45 connector
100BaseFX ST connectors
Wave length: 1300 nm
Fiber type:
multimode 62.5/125 m or 50/125 m
Protocols available: ModBus® TCP/IP
DNP over TCP/IP and UDP/IP
IEC 870-5-104
Http, ftp, tftp (allow the use of a standard Internet browser)
Typical distance: 1.65 km
Response time to ModBus commands: 10 ms Typical
Isolation: 2 kV
In Models C and D, the 10/100BaseTX port is selected by an internal switch (see 3.3.3)
Two witness LED’s for transmission and reception are included
Operating temperature:
- 10C to + 60C
Storage temperature:
- 40C to + 80C
Humidity (non condensing): 95%
Altitude Up to 2000 m
Installation category II
Net weight: 5 kg
Packaged: 6 kg
Package dimensions: 30x40x40 cm (DxWxH)
