6-18 F650 Digital Bay Controller GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
6.2.10 FLEX CURVES
This screen can be accessed at Actual> Status > Flex Curves, and it includes the internal flex curves status.
If the LED associated to the FlexCurve status is lit up, this indicates that the user curve has been configured with new
values (not default values).
Table 6–26: FLEX CURVES STATUS
6.2.11 SYSTEM INFO
This screen can monitor the system parameters and the internal status of the Relay operative system. It is only available
with password provided by the manufacturer.
6.2.12 RECORD STATUS
This screen shows part of the information related to the different records stored in the Relay, such as:
6.2.12.1 FAULT REPORTS
Actual> Status > Records Status > Fault Reports
Table 6–27: FAULT REPORT STATUS
FAULT REPORT TRIGG: This signal indicates whether the signal that initiates the calculation of the distance to the fault
has been activated.
CLEAR FAULT REPORTS: This signal indicates the reset of fault reports.
FAULT DATE: Date and time of the last fault produced in the relay. In format (Day/Month/year
Hour:minutes:seconds.milliseconds)
FAULT TYPE: Type of the last fault produced in the Relay (phase to ground, phase to phase, three-phase,
etc).
FAULT LOCATION: Location of the last fault produced in the relay.
FAULT REPORT NUMBER: Number of fault reports available in the relay (ten is the maximum number of records
supported by the relay).
FLEX CURVES STATUS
FLEXCURVE A STATUS
FLEXCURVE B STATUS
FLEXCURVE C STATUS
FLEXCURVE D STATUS
FAULT REPORT STATUS
FAULT REPORT TRIGG
CLEAR FAULT REPORTS
FAULT DATE
FAULT TYPE
FAULT LOCATION
FAULT REPORT NUMBER
