5-4 F650 Digital Bay Controller GE Multilin
5.2 PRODUCT SETUP 5 SETPOINTS
5
5.2.1.4 DNP3 SLAVE
Physical port, Slave Address for DNP, IP Addresses for Masters, TCP/UDP Port, Unsolicited Response parameters, Analog
scale factors and deadbands, message fragment size, Binary input block. For more detail information go to appendix C in
this manual.
Table 5–5: DNP PROTOCOL SETPOINTS
PRODUCT SETUP>COMMUNICATION SETPOINTS >DNP3 SLAVE
DNP3 SLAVE 1 > DNP3 SLAVE 2 > DNP3 SLAVE 3
Name Default Value Step Range
Physical Port NONE [COM1:COM2:NETWORK]
Address 255 [0 : 65534]
IP Addr Client1 Oct1 0 [0 : 255]
IP Addr Client1 Oct2 0 [0 : 255]
IP Addr Client1 Oct3 0 [0 : 255]
IP Addr Client1 Oct4 0 [0 : 255]
IP Addr Client2 Oct1 0 [0 : 255]
IP Addr Client2 Oct2 0 [0 : 255]
IP Addr Client2 Oct3 0 [0 : 255]
IP Addr Client2 Oct4 0 [0 : 255]
IP Addr Client3 Oct1 0 [0 : 255]
IP Addr Client3 Oct2 0 [0 : 255]
IP Addr Client3 Oct3 0 [0 : 255]
IP Addr Client3 Oct4 0 [0 : 255]
IP Addr Client4 Oct1 0 [0 : 255]
IP Addr Client4 Oct2 0 [0 : 255]
IP Addr Client4 Oct3 0 [0 : 255]
IP Addr Client4 Oct4 0 [0 : 255]
IP Addr Client5 Oct1 0 [0 : 255]
IP Addr Client5 Oct2 0 [0 : 255]
IP Addr Client5 Oct3 0 [0 : 255]
IP Addr Client5 Oct4 0 [0 : 255]
TCP/UDP Port 20000 [0 : 65535]
Unsol Resp Function DISABLED [DISABLED – ENABLED]
Unsol Resp TimeOut 5 [0 : 60]
Unsol Resp Max Ret 10 [0 : 255]
Unsol Resp Dest Adr 200 [0 : 65535]
Current Scale Factor 1 [0.00001-0.0001-0.001-0.01-0.1-1-10-100-1000]
Voltage Scale Factor 1 [0.00001-0.0001-0.001-0.01-0.1-1-10-100-1000]
Power Scale Factor 1 [0.00001-0.0001-0.001-0.01-0.1-1-10-100-1000]
Energy Scale Factor 1 [0.00001-0.0001-0.001-0.01-0.1-1-10-100-1000]
Other Scale Factor 1 [0.00001-0.0001-0.001-0.01-0.1-1-10-100-1000]
Current Deadband 30000 [0 : 65535]
Voltage Deadband 30000 [0 : 65535]
Power Deadband 30000 [0 : 65535]
Energy Deadband 30000 [0 : 65535]
Other Deadband 30000 [0 : 65535]
Msg Fragment Size 240 [30 : 2048]
Binary Input Block 1 CTL EVENTS 1-16
Binary Input Block 2 CTL EVENTS 17-32
Binary Input Block 3 CTL EVENTS 33-48
Binary Input Block 4 CTL EVENTS 49-64
Binary Input Block 5 CTL EVENTS 65-80
