GE Multilin F650 Digital Bay Controller 5-73
5 SETPOINTS 5.4 PROTECTION ELEMENTS
5
By adding 90º to the angles shown on the table, the represented units would be similar but with Reactive Power instead of
Active Power.
Any other angle would provide a mixed Protection Between Active and Reactive power.
A different angle selection for Stage 1 and Stage 2 could provide in a single unit, a Reactive and Active power limitation. For
example, using the following values:
Dir Power Angle 1(RCA) 0º
Stage 1 Tap 0
Dir Power Angle 2(RCA) 90º
Stage 2 Tap 0
We would obtain a mixed Protection Between figure (d) and figure (e).
b) SETPOINTS
Table 5–67: 32 UNIT SETPOINTS
The snapshot event setpoint enables or disables the snapshot event generation for this unit.
Function: Enables or disables the directional element.
Blk Time After Close: In seconds. This setpoints allow to block the 32 element during the time specified in
the setpoint after the breaker switches from OPEN to CLOSED.
Dir Power Angle (1-2) (RCA): This setpoint specifies the relay characteristic angle (RCA) for the directional power
unit. This setpoint provides ability to respond to the function in any direction defined
(active forward power, active low forward power, etc.)
SETPOINT > PROTECTION ELEMENTS > POWER > DIRECTIONAL POWER>
DIRECTIONAL POWER 1> DIRECTIONAL POWER 2 > DIRECTIONAL POWER 3
SETPOINT DESCRIPTION NAME DEFAULT
VALUE
STEP RANGE
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Block from off-line Blk Time After Close 0.00 0.01 s [0.00 : 900.00]
Directional Angle for stage 1 (RCA1) Dir Power Angle 1 0.00 1 Deg [0.00 : 359.99]
Pickup level for stage 1 Stage 1 Tap 10.00 0.01MW [-10000.00 : 10000.00]
Trip time for stage 1 Stage 1 Time 60.00 0.01 s [0.00 : 900.00]
Directional Angle for stage 2 (RCA2) Dir Power Angle 2 0.00 1 Deg [0.00 : 359.99]
Pickup level for stage 2 Stage 2 Tap 20.00 0.01MW [-10000.00 : 10000.00]
Trip time for stage 2 Stage 2 Time 60.00 0.01 s [0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
