6-10 F650 Digital Bay Controller GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
The AUTORECLOSE INTERNAL STATUS are internal signals provided by the autoreclose unit:
AR CLOSE BREAKER: Breaker close command given by the autoreclose
AR OUT OF SERVICE: Autoreclose out of service (Disabled)
AR READY: Autoreclose in service
AR LOCKOUT: Autoreclose in lockout status (finished cycled-definite trip)
AR BLOCK: Autoreclose blocked (by input, logic, others, etc).
AR RCL IN PROGRESS: Cycle in course (autoreclose in progress).
AR LCK BY ANOMALY: Autoreclose in “Lockout” by anomaly.
AR LCK BY FAIL OPEN: Autoreclose in “Lockout” by a failure in opening the breaker.
AR LCK BY FAIL CLOSE: Autoreclose in “Lockout” by a failure in closing the breaker.
AR LCK BY USER: Autoreclose in “Lockout” by manual close.
AR LCK BY CONDS: Autoreclose in “Lockout” by conditions. See input conditions configuration.
AR LCK BY TRIPS: Autoreclose in “Lockout” by maximum number of trips.
AR LCK BY SHOTS: Autoreclose in “Lockout” at the end of cycle – Definite trip.
AR BLK AFTER 1 SHOT: Signal sent by the autoreclose after the 1
st
shot.
AR BLK AFTER 2 SHOT: Signal sent by the autoreclose after the 2
nd
shot.
AR BLK AFTER 3 SHOT: Signal sent by the autoreclose after the 3
rd
shot.
AR BLK AFTER 4 SHOT: Signal sent by the autoreclose after the 4
th
shot.
AR BLOCK BY LEVEL: Autoreclose blocked by level. See AR block signals configuration
AR BLOCK BY PULSE: Autoreclose blocked by pulse. See AR block signals configuration
AR STATUS: Autoreclose status (in service – out of service)
AR LOCKOUT MODE: Relay “Lockout” status.
AR BLOCK MODE: Relay “Block” status
