GE Multilin F650 Digital Bay Controller 6-23
6 ACTUAL VALUES 6.3 METERING
6
6.3.1.2 VOLTAGE
Actual> Metering > Primary Values > Voltage
Table 6–35: VOLTAGE PRIMARY VALUES
6.3.1.3 POWER
Actual> Metering > Primary Values > Power
Table 6–36: POWER PRIMARY VALUES
NOTE: If voltage inputs are configured in Delta connection and the auxiliary voltage input is set as Vx, measurement of
single phase power value cannot be duly calculated, and therefore, its value will be zero. For the three-phase power value,
the system uses the ARON method, or two-wattmeters method.
DESCRIPTION UNITS
PT Ratio N/A
Va Angle Deg
Vb Angle Deg
Vc Angle Deg
Vn Angle Deg
Vx Angle Deg
Vab Angle Deg
Vbc Angle Deg
Vca Angle Deg
V0 Primary KV
V1 Primary KV
V2 Primary KV
Vab Primary KV
Vbc Primary KV
Vca Primary KV
Va Primary KV
Vb Primary KV
Vc Primary KV
Vn Primary KV
Vx Primary KV
VBB Primary KV
VL Primary KV
DESCRIPTION UNITS
Phase A Real Pwr MW
Phase A Reactive Pwr MVAr
Phase A Apparent Pwr MVA
Phase B Real Pwr MW
Phase B Reactive Pwr MVAr
Phase B Apparent Pwr MVA
Phase C Real Pwr MW
Phase C Reactive Pwr MVAr
Phase C Apparent Pwr MVA
3 Phase Real Pwr MW
3 Phase Reactive Pwr MVAr
3 Phase Apparent Pwr MVA
Phase A Power Factor N/A
Phase B Power Factor N/A
Phase C Power Factor N/A
3 Phase Power Factor N/A
