10-2 F650 Digital Bay Controller GE Multilin
10.1 EXAMPLE1: COMMUNICATION & PROTECTION SETTINGS PROCEDURE 10 APPLICATION EXAMPLES
10
Press ESC key once.
Move rotating knob counterclockwise to General Settings and press it down. General Settings 0 will be displayed now.
Press rotating knob down again.
Set ModBus Port Number to 502 and press rotating knob down.
Move counterclockwise the rotating knob to find ModBus Address COM1 and press it down.
Set ModBus Address COM1 to 254 with the rotating knob and then press it down.
Move clockwise the rotating knob to find Press Intro to End and press it down to validate the setting.
Connect a crossover 10/100 MB Ethernet cable from PC to the relay.
Open the EnerVista 650 SETUP program in the PC and under Communication î Computer menu and set:
IP Address 192.168.37.125
Port 502
Unit Identifier 254
Control Type to ModBus/TCP
Startup Mode to Communicate with relay
Click ON key.
The program will start connection with the relay showing the progress screen.
Move rotating knob clockwise IP Address OCT 3 Set to 37 with rotating knob and press it down
Move rotating knob clockwise IP Address OCT 4 Set to 125 with rotating knob and press it down
Move rotating knob clockwise Netmask OCT 1 Set to 255 with rotating knob and press it down
Move rotating knob clockwise Netmask OCT 2 Set to 255 with rotating knob and press it down
Move rotating knob clockwise Netmask OCT 3 Set to 255 with rotating knob and press it down
Move rotating knob clockwise Netmask OCT 4 Set to 0 with rotating knob and press it down
Move rotating knob clockwise Netway IP OCT 1 Leave default setting without any change
Move rotating knob clockwise Netway IP OCT 2 Leave default setting without any change
Move rotating knob clockwise Netway IP OCT 3 Leave default setting without any change
Move rotating knob clockwise Netway IP OCT 4 Leave default setting without any change
Move rotating knob clockwise Press INTRO Press down the rotating knob to validate settings
