GE Multilin F650 Digital Bay Controller A-23
APPENDIX A A.1 LOGIC OPERANDS
A
Sobrefrecuencia - Overfrequency
OVERFREQ1 BLOCK Overfrequency element block Group 1
OVERFREQ1 PKP Overfrequency element pickup Group 1
OVERFREQ1 OP Overfrequency element operation Group 1
OVERFREQ2 BLOCK Overfrequency element block Group 2
OVERFREQ2 PKP Overfrequency element pickup Group 2
OVERFREQ2 OP Overfrequency element operation Group 2
OVERFREQ3 BLOCK Overfrequency element block Group 3
OVERFREQ3 PKP Overfrequency element pickup Group 3
OVERFREQ3 OP Overfrequency element operation Group 3
Subfrecuencia - Underfrequency
UNDERFREQ1 BLOCK Underfrequency element block Group 1
UNDERFREQ1 PKP Underfrequency element pickup Group 1
UNDERFREQ1 OP Underfrequency element operation Group 1
UNDERFREQ2 BLOCK Underfrequency element block Group 2
UNDERFREQ2 PKP Underfrequency element pickup Group 2
UNDERFREQ2 OP Underfrequency element operation Group 2
UNDERFREQ3 BLOCK Underfrequency element block Group 3
UNDERFREQ3 PKP Underfrequency element pickup Group 3
UNDERFREQ3 OP Underfrequency element operation Group 3
Broken Conductor
BROKEN CONDUCT1
BLK
Broken conductor block Group 1
BROKEN CONDUCT1
PKP
Broken conductor element Pickup Group 1
BROKEN CONDUCT1
OP
Broken conductor element operation Group 1
BROKEN CONDUCT2
BLK
Broken conductor block Group 2
BROKEN CONDUCT2
PKP
Broken conductor element Pickup Group 2
BROKEN CONDUCT2
OP
Broken conductor element operation Group 2
BROKEN CONDUCT3
BLK
Broken conductor block Group 3
BROKEN CONDUCT3
PKP
Broken conductor element Pickup Group 3
BROKEN CONDUCT3
OP
Broken conductor element operation Group 3
Forward Power(32FP)
FWD PWR1 BLOCK Forward power element block Group 1
FWD PWR1 STG1 PKP Forward Power element pickup level 1 Group 1
FWD PWR1 STG1 OP Forward Power element operation level 1 Group 1
FWD PWR1 STG2 PKP Forward Power element pickup level 2 Group 1
FWD PWR1 STG2 OP Forward Power element operation level 2 Group 1
FWD PWR2 BLOCK Forward power element block Group 2
FWD PWR2 STG1 PKP Forward Power element pickup level 1 Group 2
FWD PWR2 STG1 OP Forward Power element operation level 1 Group 2
FWD PWR2 STG2 PKP Forward Power element pickup level 2 Group 2
FWD PWR2 STG2 OP Forward Power element operation level 2 Group 2
FWD PWR3 BLOCK Forward power element block Group 3
FWD PWR3 STG1 PKP Forward Power element pickup level 1 Group 3
FWD PWR3 STG1 OP Forward Power element operation level 1 Group 3
FWD PWR3 STG2 PKP Forward Power element pickup level 2 Group 3
FWD PWR3 STG2 OP Forward Power element operation level 2 Group 3
