B-22 F650 Digital Bay Controller GE Multilin

B.1 MODBUS PROTOCOL FOR 650 APPENDIX B

0X11,0Xd1,0Xd0,0X10,0Xf0,0X30,0X31,0Xf1,0X33,0Xf3,

0Xf2,0X32,0X36,0Xf6,0Xf7,0X37,0Xf5,0X35,0X34,0Xf4,

0X3c,0Xfc,0Xfd,0X3d,0Xff,0X3f,0X3e,0Xfe,0Xfa,0X3a,

0X3b,0Xfb,0X39,0Xf9,0Xf8,0X38,0X28,0Xe8,0Xe9,0X29,

0Xeb,0X2b,0X2a,0Xea,0Xee,0X2e,0X2f,0Xef,0X2d,0Xed,

0Xec,0X2c,0Xe4,0X24,0X25,0Xe5,0X27,0Xe7,0Xe6,0X26,

0X22,0Xe2,0Xe3,0X23,0Xe1,0X21,0X20,0Xe0,0Xa0,0X60,

0X61,0Xa1,0X63,0Xa3,0Xa2,0X62,0X66,0Xa6,0Xa7,0X67,

0Xa5,0X65,0X64,0Xa4,0X6c,0Xac,0Xad,0X6d,0Xaf,0X6f,

0X6e,0Xae,0Xaa,0X6a,0X6b,0Xab,0X69,0Xa9,0Xa8,0X68,

0X78,0Xb8,0Xb9,0X79,0Xbb,0X7b,0X7a,0Xba,0Xbe,0X7e,

0X7f,0Xbf,0X7d,0Xbd,0Xbc,0X7c,0Xb4,0X74,0X75,0Xb5,

0X77,0Xb7,0Xb6,0X76,0X72,0Xb2,0Xb3,0X73,0Xb1,0X71,

0X70,0Xb0,0X50,0X90,0X91,0X51,0X93,0X53,0X52,0X92,

0X96,0X56,0X57,0X97,0X55,0X95,0X94,0X54,0X9c,0X5c,

0X5d,0X9d,0X5f,0X9f,0X9e,0X5e,0X5a,0X9a,0X9b,0X5b,

0X99,0X59,0X58,0X98,0X88,0X48,0X49,0X89,0X4b,0X8b,

0X8a,0X4a,0X4e,0X8e,0X8f,0X4f,0X8d,0X4d,0X4c,0X8c,

0X44,0X84,0X85,0X45,0X87,0X47,0X46,0X86,0X82,0X42,

0X43,0X83,0X41,0X81,0X80,0X40 };

UCHAR chi;

UCHAR clo;

USHORT ui;

chi = 0xff;

clo = 0xff;

while(us--)

{ ui = chi ^ *p++;

chi = clo ^ hi[ui];

clo = lo[ui];

}

ui = chi;

ui = ui << 8;

ui = ui | clo; // motorola format

return(ui);

}
