GE
P
ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 4 - Functional Checks 4-31
PRELIMINARY
3
Under the Special Instructions area, activate the Loops
checkbox and select the required number of Loops from
the combo box.
4
Adjacent to On Fail, select either Stop or Continue, as
required.
5 Trackball to the Start button and press Set
The test commences.
When the ACW BPF Test sequence is complete, the
View Test Log window opens automatically, listing the
test performed and showing whether it passed or failed
- see the examples in Figure 7-49 on page 7-80 through
Figure 7-52 on page 7-83.
6
Use the scroll arrows at the bottom of the Reports
window to scroll through the channels and view the
corresponding results.
ACW HPF Test
1 Trackball to ACW HPF Test and press Set.
2
Disconnect any probes currently connected to the
system and make sure that nothing is touching the probe
connectors.
3
Under the Special Instructions area, activate the Loops
checkbox and select the required number of Loops from
the combo box.
4
Adjacent to On Fail, select either Stop or Continue, as
required.
5 Trackball to the Start button and press Set
The test commences.
When the ACW HPF Test sequence is complete, the
View Test Log window opens automatically, listing the
test performed and showing whether it passed or failed
- see the examples in Figure 7-54 on page 7-85 and
Figure 7-55 on page 7-86.
6
Use the scroll arrows at the bottom of the Reports
window to scroll through the channels and view the
corresponding results.
PENCIL RX TEST
Important: When performing this test, no probe should be connected to the system and nothing should be
touching the probe connectors!
1 Trackball to PENCIL RX Test and press Set.
2
Disconnect any probes currently connected to the
system and make sure that nothing is touching the probe
connectors.
3
Under the Special Instructions area, activate the Loops
checkbox and select the required number of Loops from
the combo box.
4
Adjacent to On Fail, select either Stop or Continue, as
required.
Table 4-12 Front End Tests (cont’d)
Step Task Expected Result(s)
