ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-205
PRELIMINARY
3.) Lead the cables via the right cable hook (Figure 8-256) and make one or two loops to shorten the
cable.
4.) Insert the probe in the probe holder as shown in Figure 8-258.
5.) Similarly, route the left probe cable/s via the cable holder and the left cable hook.
6.) Route the AC power cable via the AC Power Cable hook and lead it upwards as shown in
Figure 8-259.
NOTE: Whenever moving the Vivid S5 N / Vivid S6 N scanner, make sure the system is prepared correctly, as
shown in Figure 8-260 on page 8-206.
Figure 8-258 Probe in Probe Holder
Figure 8-259 AC Power Cable Connected and Routed
