Fundamentals | File management
3
To display the dependent files, set the machine
parameter dependentFiles (no. 122101) to MANUAL.
Selecting drives, directories and files
Call the file manager by pressing the PGM MGT
key
Navigate with a connected mouse or use the arrow keys or the soft
keys to move the cursor to the desired position on the screen:
Moves the cursor from the left to the right
window, and vice versa
Moves the cursor up and down within a window
Moves the cursor one page up or down within a
window
Step 1: Select drive
Move the highlight to the desired drive in the left window
Select a drive: Press the SELECT soft key, or
Press the ENT key
Step 2: Select a directory
Move the highlight to the desired directory in the left window
The right-hand window automatically shows all files stored in
the highlighted directory
110
