HEIDENHAIN TNC 620 Programming Station

Programming Qparameters | Preassigned Q parameters
Measurement results from touch probe cycles
Further information: User's Manual for Programming of Measuring
Cycles for Workpieces and Tools
Parameters Measured actual values
Q150 Angle of a straight line
Q151 Center in main axis
Q152 Center in secondary axis
Q153 Diameter
Q154 Pocket length
Q155 Pocket width
Q156 Length of the axis selected in the cycle
Q157 Position of the centerline
Q158 Angle in the A axis
Q159 Angle in the B axis
Q160 Coordinate of the axis selected in the cycle
Parameters Measured deviation
Q161 Center in main axis
Q162 Center in secondary axis
Q163 Diameter
Q164 Pocket length
Q165 Pocket width
Q166 Measured length
Q167 Position of the centerline
Parameters Determined space angle
Q170 Rotation about the A axis
Q171 Rotation about the B axis
Q172 Rotation about the C axis
Parameters Workpiece status
Q180 Good
Q181 Rework
Q182 Scrap
