Programming Q Parameters | Additional functions
10
398
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
Values for LAC and VSC
0 Index of the NC axis for which the LAC
weighing run will be performed or was last
performed (X to W = 1 to 9)
0
2 Total inertia determined by the LAC weighing
run in [kgm
2
] (with A/B/C rotary axes) or total
mass in [kg] (with X/Y/Z linear axes)
71
1 0 Cycle 957 Retraction from thread
Freely available memory area for OEM cycles
72 0-39 0 to 30 Freely available memory area for OEM
cycles. The values are only reset by the
control during a control reboot (= 0).
With “Cancel,” the values are not reset to
the value that they had at the time of execu-
tion.
Up to and including 597110-11: only NR 0-9
and IDX 0-9
Starting with 597110-12: NR 0-39 and IDX
0-30
Freely available memory area for user cycles
73 0-39 0 to 30 Freely available memory area for user cycles
The values are only reset by the control
during a control reboot (= 0).
With “Cancel,” the values are not reset to
the value that they had at the time of execu-
tion.
Up to and including 597110-11: only NR 0-9
and IDX 0-9
Starting with 597110-12: NR 0-39 and IDX
0-30
Minimum spindle speed
90 1 Spindle ID Minimum spindle speed of the lowest gear
range. If no gear ranges are configured, the
spindle speed is taken from the parameter
set with index 0.
Index 99 = active spindle
Tool compensation
1 1 = without
oversize 2 =
with oversize
3 = with
oversize and
oversize from
TOOL CALL
Active radius200
2 1 = without
oversize 2 =
with oversize
3 = with
Active length
