Programming aids | GOTO function
6
6.1 GOTO function
Using the GOTO key
Jumping with the GOTO key
Use the GOTO key to jump to a specific location in the NC program,
regardless of the active operating mode.
Proceed as follows:
Press the GOTO key
The control opens a pop-up window.
Enter a number
Select the jump statement by soft key, e.g. move
down the number of lines entered
The control provides the following options:
Soft key Function
Move up the number of lines entered
Move down the number of lines entered
Jump to the block number entered
Use the GOTO function only during programming and
testing of NC programs. Use the Block scan function
during program run.
Further information: User's Manual for Setup, Testing
and Running NC Programs
Quick selection with the GOTO key
With the GOTO key, you can open the Smart Select window that
makes it easy for you to select special functions or cycles.
To select special functions:
Press the SPEC FCT key
Press the GOTO key
The control displays a pop-up window showing a
structural view of the special functions
Select the desired function
Further information: User's Manual for Programming of Machining
Cycles
Opening the selection window with the GOTO key
When the control provides a selection menu, you can use the GOTO
key to open the selection window. This allows you to view the
available entries.
192
HEIDENHAIN | TNC620 | Klartext Programming User's Manual | 01/2022
