Programming Aids | Cutting data calculator
5
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
211
Functions in the cutting data calculator:
Soft key Function
Load the spindle speed from the cutting data
calculator form into an open dialog field.
Load the feed rate from the cutting data calcula-
tor form into an open dialog field.
Load the cutting speed from the cutting data
calculator form into an open dialog field.
Load the feed per tooth from the cutting data
calculator form into an open dialog field.
Load the feed per revolution from the cutting
data calculator form into an open dialog field.
Load the tool radius into the cutting data calcu-
lator form
Load the spindle speed from the open dialog
field into the cutting data calculator form
Load the feed rate from the open dialog field
into the cutting data calculator form
Load the feed per revolution from the open
dialog field into the cutting data calculator form
Load the feed per tooth from the open dialog
field into the cutting data calculator form
Load the value from an open dialog field into
the cutting data calculator form
Switch to the pocket calculator
Move the cutting data calculator in the direction
of the arrow
Use inch values in the cutting data calculator
Close the cutting data calculator
