Programming Qparameters | Preassigned Q parameters
9
Tool length: Q114
The current value for the tool length is assigned to Q114.
The control remembers the current tool length even if the
power is interrupted.
Coordinates after probing during program run
The parameters Q115 to Q119 contain the coordinates of the
spindle position at the instant of probing during programmed
measurement with the 3-D touch probe. The coordinates are
referenced to the preset that is active in Manual operation mode.
The length of the stylus and the radius of the ball tip are not
compensated in these coordinates.
Parameter Coordinate axis
Q115 X axis
Q116 Y axis
Q117 Z axis
Q118 4th axis
Machine-dependent
Q119 5th axis
Machine-dependent
Deviation between actual and nominal value during
automatic tool measurement; for example, with the
TT160
Parameter Deviation of actual from nominal value
Q115 Tool length
Q116 Tool radius
Tilting the working plane with workpiece angles:
Coordinates calculated by the control for rotary axes
Parameter Coordinates
Q120 A axis
Q121 B axis
Q122 C axis
