Multiple-axis machining | The PLANE function: Tilting the working plane (option 8)
Resetting PLANE function
Example
25 PLANE RESET MOVE DIST50 F1000
Show the soft-key row with special functions
Press the TILT MACHINING PLANE soft key
The control displays the available PLANE
functions in the soft-key row
Select the reset function
Specify whether the control should automatically
move the tilting axes to home position (MOVE or
TURN) or not (STAY)
Further information: "Automatic tilting into
position MOVE/TURN/STAY", Page 451
Press the END key.
The PLANE RESET function resets the active tilt and
the angles (PLANE function or Cycle 19) (angle = 0 and
function inactive). It does not need to be defined more
than once.
Deactivate tilting in the Manual operation mode in the
3-D ROT menu.
Further information: User's Manual for Setup, Testing
and Running NC Programs
11
HEIDENHAIN | TNC620 | Klartext Programming User's Manual | 01/2022
435
