HEIDENHAIN TNC 620 Programming Station User Manual

Multiple-Axis Machining | The PLANE function: Tilting the working plane (option 8)
13
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
535
13.2 The PLANE function: Tilting the working
plane (option 8)
Introduction
Refer to your machine manual.
The machine manufacturer must enable the functions
for tilting the working plane!
You can only use the PLANE function in its entirety on
machines having at least two rotary axes (table axes,
head axes or combined axes). An exception is the
PLANE AXIAL function. PLANE AXIAL can also be used
on a machine which has only one programmed rotary
axis.
The PLANE functions provide powerful options to define tilted
working planes in various ways.
The parameter definition of the PLANE functions is subdivided into
two parts:
The geometric definition of the plane, which is different for each
of the available PLANE functions.
The positioning behavior of the PLANE function, which is
independent of the plane definition and is identical for all PLANE
functions
Further information: "Specifying the positioning behavior of the
PLANE function", page 554
NOTICE
Danger of collision!
Cycle 8 MIRROR IMAGE may have different effects in conjunction
with the Tilt working plane function. The effect mainly depends
on the programming sequence, the mirrored axes and the tilting
function used. There is a danger of collision during the tilting
operation and subsequent machining.
Check the sequence and positions using a graphic simulation
Carefully test the NC program or program section in the
Program run, single block operating mode
Examples
1
Cycle 8 MIRROR IMAGE programmed before the tilting
function without rotary axes:
The tilt of the PLANE function used (except PLANE AXIAL)
is mirrored
The mirroring is effective after the tilt with PLANE AXIAL or
Cycle 19
2
Cycle 8 MIRROR IMAGE programmed before the tilting
function with a rotary axis:
The mirrored rotary axis has no effect on the tilt specified
in the PLANE function used, because only the movement
of the rotary axis is mirrored
