Programming Aids | Programming graphics
5
214
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Block number display ON/OFF
Shift the soft-key row
To show block numbers: Set the
BLOCK NO. SHOW OMIT soft key to SHOW
To hide block numbers: Set the
BLOCK NO. SHOW OMIT soft key to OMIT
Erasing the graphic
Shift the soft-key row
Erase the graphics: Press the CLEAR GRAPHICS
soft key
Showing grid lines
Shift the soft-key row
Show grid lines: Press the Show grid lines soft
key
