HEIDENHAIN TNC 620 Programming Station User Manual

Programming Q Parameters | Additional functions
10
412
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
Measure the maximum utilization of an axis
621 0 Index of physi-
cal axis
Conclude measurement of the dynamic
load and save the result in the specified Q
parameter.
Read SIK contents
0 Option no. You can explicitly determine whether the SIK
option given under IDX has been set or not.
1 = option is enabled
0 = option is not enabled
1 - You can determine whether a Feature
Content Level (for upgrade functions) is set,
and which one.
–1 = No FCL is set
<No.> = FCL that is set
2 - Read serial number of the SIK
-1 = No valid SIK in the system
630
10 - Define the type of control:
0 = iTNC 530
1 = NCK-based control (TNC 640, TNC 620,
TNC 320, TNC 128, PNC 610, ...)
Workpiece counter
1 - Planned workpieces.
In Test Run operating mode the counter
generally generates the value 0.
2 - Already machined workpieces.
In Test Run operating mode the counter
generally generates the value 0.
920
12 - Workpieces still to be machined.
In Test Run operating mode the counter
generally generates the value 0.
Read and write data of current tool
1 - Tool length L
2 - Tool radius R
3 - Tool radius R2
4 - Oversize for tool length DL
5 - Tool radius oversize DR
6 - Tool radius oversize DR2
7 - Tool locked TL
0 = not locked, 1 = locked
8 - Number of the replacement tool RT
9 - Maximum tool age TIME1
10 - Maximum tool age TIME2 at TOOL CALL
11 - Current tool age CUR.TIME
950
12 - PLC status
