HEIDENHAIN TNC 620 Programming Station User Manual

Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
819
Comparison: Touch probe cycles in the Manual
operation and Electronic handwheel modes of
operation
Cycle TNC 620 iTNC 530
Touch-probe table for managing 3-D touch probes X –
Calibrating the effective length X, option 17 X
Calibrating the effective radius X, option 17 X
Measuring a basic rotation using a line X, option 17 X
Setting the preset on any axis X, option 17 X
Setting a corner as preset X, option 17 X
Setting a circle center as preset X, option 17 X
Setting a center line as preset X, option 17 X
Measuring a basic rotation using two holes/cylindrical studs X, option 17 X
Setting the preset using four holes/cylindrical studs X, option 17 X
Setting the circle center using three holes/cylindrical studs X, option 17 X
Determine and offset misalignment of a plane X, option 17 –
Support of mechanical touch probes by manually capturing the current
position
By soft key or
hard key
By hard key
Write measurement values to the preset table X, option 17 X
Write measurement values to the datum table X, option 17 X
