Tables and overviews | System data
15
No. IDX Contents Replacement function
3 - Status of collision monitoring (old) Can be activated and deactivat-
ed in the NC program
4 - Status of collision monitoring (new) Can be activated and deactivat-
ed in the NC program
ID 310 Modifications of geometrical behavior
116 - M116: –1 = On, 0 = Off
126 - M126: –1 = On, 0 = Off
ID 350 Touch-probe data
10 - TS: Touch-probe axis ID 20 NR 3
11 - TS: Effective ball radius ID 350 NR 52
12 - TS: Effective length ID 350 NR 51
13 - TS: Ring gauge radius
14 1/2 TS: Center offset in reference/minor axis ID 350 NR 53
15 - TS: Direction of center offset relative to 0°
position
ID 350 NR 54
20 1/2/3 TT: Center point X/Y/Z ID 350 NR 71
21 - TT: Plate radius ID 350 NR 72
22 1/2/3 TT: 1st probing position X/Y/Z Cfgread
23 1/2/3 TT: 2nd probing position X/Y/Z Cfgread
24 1/2/3 TT: 3rd probing position X/Y/Z Cfgread
25 1/2/3 TT: 4th probing position X/Y/Z Cfgread
ID 370 Touch probe cycle settings
1 - Do not move to set-up clearance in Cycle
0.0 and 1.0 (as with ID990 NR1)
ID 990 NR 1
2 - MP 6150 Rapid traverse for measurement ID 350 NR 55 IDX 1
3 - MP 6151 Machine rapid traverse as rapid
traverse for measurement
ID 350 NR 55 IDX 3
4 - MP 6120 Feed rate for measurement ID 350 NR 55 IDX 2
5 - MP 6165 Angle tracking on/off ID 350 NR 57
ID 501 Datum table (REF system)
Line Column Value in datum table Preset table
ID 502 Preset table
Line Column Read the value from preset table, taking into
account the active machining system
ID 503 Preset table
Line Column Read the value directly from the preset table ID 507
ID 504 Preset table
Line Column Read the basic rotation from the preset
table
ID 507 IDX 4-6
ID 505 Datum table
1 - 0 = No datum table selected
