Programming Q Parameters | Additional functions
10
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
413
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
13 - Tooth length in the tool axis LCUTS
14 - Maximum plunge angle ANGLE
15 - TT: Number of tool teeth CUT
16 - TT: Wear tolerance for length LTOL
17 - TT: Wear tolerance for radius RTOL
18 - TT: Direction of rotation DIRECT
0 = positive, –1 = negative
19 - TT: Offset in plane R-OFFS
R = 99999.9999
20 - TT: Offset in length L-OFFS
21 - TT: Break tolerance for length LBREAK
22 - TT: Break tolerance for radius RBREAK
28 - Maximum spindle speed [rpm] NMAX
32 - Point angle TANGLE
34 - LIFTOFF allowed
(0 = No, 1 = Yes)
35 - Wear tolerance for radius R2TOL
36 - Tool type TYPE (miller = 0, grinder = 1, ...
touch probe = 21)
37 - Corresponding line in the touch-probe table
38 - Timestamp of last use
39 - ACC
40 - Pitch for thread cycles
44 - Exceeding the tool life
Freely available memory area for tool management
956 0-9 - Freely available data area for tool manage-
ment. The data is not reset when the
program is aborted.
Transformation data for general tools
1 - Position within the tool system explicitly
defined:
2 - Position defined by directions:
3 - Shift in X
4 - Shift in Y
5 - Shift in Z
6 - X component of the Z direction
7 - Y component of the Z direction
8 - Z component of the Z direction
9 - X component of the X direction
960
10 - Y component of the X direction
