Tables and overviews | System data
15
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
System jump addresses
1 - Label number or label name (string or QS)
jumped to during M2/M30 instead of ending
the current NC program.
Value = 0: M2/M30 have the normal effect
2 - Label number or label name (string or QS)
jumped to in the event of FN14: ERROR with
the NC CANCEL reaction instead of abort-
ing the NC program with an error message.
The error number programmed in the FN14
command can be read under ID992 NR14.
Value = 0: FN14 has the normal effect.
13
3 - Label number or label name (string or QS)
jumped to in the event of an internal server
error (SQL, PLC, CFG) or with erroneous file
operations (FUNCTION FILECOPY, FUNCTION
FILEMOVE, or FUNCTION FILEDELETE)
instead of aborting the NC program with an
error message.
Value = 0: Error has the normal effect.
Indexed access to Q parameters
11 Q parameter
number
Reads Q(IDX)
12 QL parameter
no.
Reads QL(IDX)
15
13 QR parameter
no.
Reads QR(IDX)
Machine status
1 - Active tool number
2 - Prepared tool number
3 - Active tool axis
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
4 - Programmed spindle speed
5 - Active spindle condition
-1 = spindle condition not defined
0 = M3 active
1 = M4 active
2 = M5 active after M3
3 = M5 active after M4
7 - Active gear range
8 - Active coolant status
0 = off, 1 = on
9 - Active feed rate
10 - Index of prepared tool
20
11 - Index of active tool
552
