Programming Q Parameters | Additional functions
10
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
405
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
Global Program Settings (GPS): Global activation status
330 0 - 0 = No GPS setting is active
1 = Any GPS setting is active
Global Program Settings (GPS): Individual activation status
0 - 0 = No GPS setting is active
1 = Any GPS setting is active
1 - GPS: Basic rotation
0 = Off, 1 = On
3 Axis GPS: Mirroring
0 = Off, 1 = On
Index: 1 - 6 (X, Y, Z, A, B, C)
4 - GPS: Shift in the modified workpiece system
0 = Off, 1 = On
5 - GPS: Rotation in input system
0 = Off, 1 = On
6 - GPS: Feed rate factor
0 = Off, 1 = On
8 - GPS: Handwheel superimpositioning
0 = Off, 1 = On
10 - GPS: Virtual tool axis VT
0 = Off, 1 = On
15 - GPS: Selection of the handwheel coordinate
system
0 = Machine coordinate system M-CS
1 = Workpiece coordinate system W-CS
2 = Modified workpiece coordinate system
mW-CS
3 = Working plane coordinate system WPL-
CS
16 - GPS: Shift in the workpiece system
0 = Off, 1 = On
331
17 - GPS: Axis offset
0 = Off, 1 = On
