HEIDENHAIN TNC 620 Programming Station User Manual

Programming Q Parameters | Additional functions
10
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
399
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
oversize and
oversize from
TOOL CALL
3 1 = without
oversize 2 =
with oversize
3 = with
oversize and
oversize from
TOOL CALL
Rounding radius R2
6 Tool no. Tool length
Index 0= active tool
Coordinate transformations
1 - Basic rotation (manual)
2 - Programmed rotation
3 - Active mirror axis. Bits 0 to 2 and 6 to 8:
Axes X, Y, Z and U, V, W
4 Axis Active scaling factor
Index: 1 - 9 (X, Y, Z, A, B, C, U, V, W)
5 Rotary axis 3D-ROT
Index: 1 - 3 (A, B, C)
6 - Tilt working plane in Program Run operating
modes
0 = Not active
–1 = Active
7 - Tilt working plane in Manual operating modes
0 = Not active
–1 = Active
210
8 QL parameter
no.
Angle of misalignment between spindle and
tilted coordinate system.
Projects the angle specified in the QL
parameter from the input coordinate system
to the tool coordinate system. If IDX is
omitted, the angle 0 is used for projection.
