Programming Q Parameters | Additional functions
10
410
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
7 - Tolerance at high speeds (MP_pathToler-
anceHi) in mm
8 - Max. derivative of jerk (MP_maxPathYank) in
m/s
4
9 - Tolerance factor for curve machining
(MP_curveTolFactor)
10 - Factor for max. permissible jerk at curvature
changes (MP_curveJerkFactor)
11 - Maximum jerk with probing movements
(MP_pathMeasJerk)
12 - Angle tolerance for machining feed rate
(MP_angleTolerance)
13 - Angle tolerance for rapid traverse (MP_angle-
ToleranceHi)
14 - Max. corner angle for polygons (MP_max-
PolyAngle)
18 - Radial acceleration with machining feed rate
(MP_maxTransAcc)
19 - Radial acceleration with rapid traverse
(MP_maxTransAccHi)
20 Index of physi-
cal axis
Max. feed rate (MP_maxFeed) in mm/min
21 Index of physi-
cal axis
Max. acceleration (MP_maxAcceleration) in
m/s
2
22 Index of physi-
cal axis
Maximum transition jerk of the axis in rapid
traverse (MP_axTransJerkHi) in m/s
2
23 Index of physi-
cal axis
Maximum transition jerk of the axis during
machining free rate (MP_axTransJerk) in m/
s
3
24 Index of physi-
cal axis
Acceleration feedforward control (MP_com-
pAcc)
25 Index of physi-
cal axis
Axis-specific jerk at low speeds (MP_axPath-
Jerk) in m/s
3
26 Index of physi-
cal axis
Axis-specific jerk at high speeds (MP_ax-
PathJerkHi) in m/s
3
27 Index of physi-
cal axis
More precise tolerance examination in
corners (MP_reduceCornerFeed)
0 = deactivated, 1 = activated
28 Index of physi-
cal axis
DCM: Maximum tolerance for linear axes in
mm (MP_maxLinearTolerance)
29 Index of physi-
cal axis
DCM: Maximum angle tolerance in [°]
(MP_maxAngleTolerance)
30 Index of physi-
cal axis
Tolerance monitoring for successive threads
(MP_threadTolerance)
