Programming Qparameters | String parameters
9
Reading system data
With the function SYSSTR you can read system data and store them
in string parameters. You select the system data through a group
number (ID) and a number.
Entering IDX and DAT is not required.
Group name, ID no. Number Meaning
Program information, 10010 1 Path of the current main program or pallet program
2 Path of the NCprogram shown in the block display
3 Path of the cycle selected with CYCL DEF 12 PGM
CALL
10 Path of the NC program selected with SEL PGM
Channel data, 10025 1 Channel name
Values programmed in the tool
call, 10060
1 Tool name
Current system time, 10321 1 to 16, 20 1: DD.MM.YYYY hh:mm:ss
2 and 16: DD.MM.YYYY hh:mm
3: DD.MM.YY hh:mm
4: YYYY-MM-DD hh:mm:ss
5 and 6: YYYY-MM-DD hh:mm
7: YY-MM-DD hh:mm
8 and 9: DD.MM.YYYY
10: D.MM.YY
11: YYYY-MM-DD
12: YY-MM-DD
13 and 14: hh:mm:ss
15: hh:mm
20: XX
"XX" stands for the two-digit number of the current
calendar week that—in accordance with ISO 8601 —
is characterized by the following:
It comprises seven days
It begins with Monday
It is numbered sequentially
The first calendar week (week 01) is the week
with the first Thursday of the Gregorian year.
Touch-probe data, 10350 50 Probe type of the active touch probe TS
70 Probe type of the active touch probe TT
73 Key name of the active touch probe TT from MP
activeTT
Data for pallet machining, 10510 1 Name of the pallet being machined
2 Path of the selected pallet table
NC software version, 10630 10 Version identifier of the NC software version
316
