HEIDENHAIN TNC 620 Programming Station User Manual

Programming Q Parameters | Additional functions
10
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
411
Group
name
Gruppen-
nummerID
Systemdaten-
nummer
Index Description
31 Index of physi-
cal axis
Form (MP_shape) of the axisCutterLoc filter
0: Off
1: Average
2: Triangle
3: HSC
4: Advanced HSC
32 Index of physi-
cal axis
Frequency MP_frequency) of the axisCutter-
Loc filter in Hz
33 Index of physi-
cal axis
Form (MP_shape) of the axisPosition filter
0: Off
1: Average
2: Triangle
3: HSC
4: Advanced HSC
34 Index of physi-
cal axis
Frequency (MP_frequency) of the axisPosi-
tion filter in Hz
35 Index of physi-
cal axis
Order of the filter for Manual operating mode
(MP_manualFilterOrder)
36 Index of physi-
cal axis
HSC mode (MP_hscMode) of the axisCut-
terLoc filter
37 Index of physi-
cal axis
HSC mode (MP_hscMode) of the axisPosi-
tion filter
38 Index of physi-
cal axis
Axis-specific jerk for probing movements
(MP_axMeasJerk)
39 Index of physi-
cal axis
Weighting of the filter error for calculating
filter deviation (MP_axFilterErrWeight)
40 Index of physi-
cal axis
Maximum filter length of position filter
(MP_maxHscOrder)
41 Index of physi-
cal axis
Maximum filter length of CLP filter
(MP_maxHscOrder)
42 - Maximum feed rate of the axis at machining
feed rate (MP_maxWorkFeed)
43 - Maximum path acceleration at machining
feed rate (MP_maxPathAcc)
44 - Maximum path acceleration at rapid traverse
(MP_maxPathAccHi)
51 Index of physi-
cal axis
Compensation of following error in the jerk
phase (MP_IpcJerkFact)
52 Index of physi-
cal axis
kv factor of the position controller in 1/s
(MP_kvFactor)
