HEIDENHAIN TNC 620 Programming Station

Basic information | Control model, software and features
1
Software options
The TNC620 features various software options, each of which can
be enabled separately by your machine tool builder. The respective
options provide the functions listed below:
Additional Axis (option 0 and option 1)
Additional axis Additional control loops 1 and 2
Advanced Function Set 1 (option 8)
Advanced functions (set 1) Machining with rotary tables
Cylindrical contours as if in two axes
Feed rate in distance per minute
Coordinate conversions:
Tilting the working plane
Interpolation:
Circular in 3 axes with tilted working plane
Advanced Function Set 2 (option 9)
Advanced functions (set 2)
Export license required
3-D machining:
3-D tool compensation through surface-normal vectors
Using the electronic handwheel to change the angle of the swivel head
during program run;
the position of the tool point remains unchanged (TCPM = Tool Center
Point Management)
Keeping the tool normal to the contour
Tool radius compensation normal to the tool direction
Manual traverse in the active tool-axis system
Interpolation:
Linear in > 4 axes (export license required)
Touch Probe Functions (option 17)
Touch probe functions Touch probe cycles:
Compensation of tool misalignment in automatic mode
Set the preset in the Manual operation mode of operation
Presetting in automatic mode
Automatically measuring workpieces
Tools can be measured automatically
HEIDENHAIN DNC (option 18)
Communication with external PC applications over COM component
Advanced Programming Features (option 19)
Expanded programming functions FK free contour programming:
Programming in HEIDENHAIN conversational format with graphic
support for workpiece drawings not dimensioned for NC
36
HEIDENHAIN | TNC620 | Klartext Programming User's Manual | 01/2022
