Multiple-axis machining | Three-dimensional tool compensation (option9)
11
Example: Block format with tool orientation
1 LN X+31.737 Y+21.954 Z+33.165 TX+0.0078922 TY–0.8764339
TZ+0.2590319 RR F1000 M128
LN: Straight line with 3-D compensation
X, Y, Z: Compensated coordinates of the straight-line
end point
TX, TY, TZ: Components of the normalized vector for
workpiece orientation
RR: Tool radius compensation
F: Feed rate
M: Miscellaneous function
Example: Block format with rotary axes
1 L X+31.737 Y+21.954 Z+33.165 B+12.357 C+5.896 RL F1000
M128
L: Straight line
X, Y, Z: Compensated coordinates of the straight-line
end point
B, C: Coordinates of the rotary axes for tool orienta-
tion
RL: Radius compensation
F: Feed rate
M: Miscellaneous function
Interpretation of the programmed path
With FUNCTION PROG PATH, you decide whether the control will
apply the 3-D radius compensation only to the delta values, just as
before, or rather to the entire tool radius. If you activate FUNCTION
PROG PATH, the programmed coordinates exactly correspond to
the contour coordinates. With FUNCTION PROG PATH OFF, you
deactivate this special interpretation.
